Features

UPS topology

Line-Interactive

Output power capacity

0.85 kVA

Output power

680 W

Waveform

Sine

Input operation voltage (min)

150 V

Input operation voltage (max)

294 V

Input frequency

47/70 Hz

Output operation voltage (max)

240 V

Output frequency

50/60 Hz

Automatic Voltage Regulation (AVR)

Yes

Heat dissipation

307 BTU/h

Number of input phases

1

Number of output phases

1

Efficiency

98%

Noise level

35 dB

Ports & interfaces

AC outlet types

C13 coupler

Power plug

C14 coupler

AC outlets quantity

4 AC outlet(s)

USB port

Yes

USB port type

USB Type-B

Serial interface

Yes

Serial interface type

RS-232

Serial ports quantity

1

Battery

Battery technology

Sealed Lead Acid (VRLA)

Battery capacity

7 Ah

Battery voltage

6 V

Number of batteries supported

4

Design

Form factor

Tower

Rack capacity

1U

Product colour

Black, Silver

Display type

LCD

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

0 - 90%

Operating altitude

0 - 3000 m

Certificates

Certification

IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA-C22.2 CE UKCA Cm Ukr KCC cTUVus BIS

Weight & dimensions

Width

438 mm

Depth

509 mm

Height

43.2 mm

Weight

13.7 kg
