Processor

Processor frequency

3 GHz

Processor manufacturer

AMD

Processor family

AMD Ryzen Embedded

Processor generation

AMD Ryzen Embedded V2000 Series

Processor model

V2546

Processor cores

6

Processor threads

12

Processor boost frequency

3.9 GHz

Processor cache

8 MB

L2 cache

3 MB

L3 cache

8 MB

Memory

Internal memory

8 GB

Internal memory type

DDR4-SDRAM

Memory clock speed

3200 MHz

Memory slots

2x SO-DIMM

Memory layout (slots x size)

2 x 4 GB

Maximum internal memory

32 GB

Storage

Total storage capacity

256 GB

Storage media

SSD

Storage drive interface

PCI Express

Storage drive size

M.2

SSD form factor

M.2

NVMe

Yes

Graphics

On-board graphics card model

AMD Radeon Graphics

Discrete GPU manufacturer

AMD

Discrete graphics card model

AMD Radeon RX 6300

Discrete graphics card memory

2 GB

Audio

Built-in speaker(s)

Yes

Network

Wi-Fi

No

Ethernet LAN

Yes

Ethernet LAN data rates

10,100,1000 Mbit/s

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

USB 2.0 ports quantity

2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

4

USB Type-C ports quantity

1

Combo headphone/mic port

Yes

DisplayPorts quantity

4

Design

Product colour

Black

Display

Display included

No

Software

Operating system installed

Windows 10 IoT Enterprise

Power

Power supply

90 W

Sustainability

Sustainability certificates

ENERGY STAR

Weight & dimensions

Width

50 mm

Depth

210 mm

Height

210 mm

Weight

1.4 kg

Packaging content

Mouse included

Yes

Keyboard included

Yes

Mouse connectivity

Wired

Keyboard connectivity

Wired

Other features

Keyboard type

USB
