Introduction

Boost and Trim Automatic Voltage Regulation (AVR)
Gives higher application availability by correcting low and high voltage conditions without using the battery.

Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.

Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.

Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.

Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Cold-start capable
Provides temporary battery power when the utility power is out.

Disconnected battery notification
Warns when a battery is not available to provide backup power.

Generator compatible
Ensures clean, uninterrupted power to protected equipment when generator power is used.

Features

Output power capacity

3 kVA

Output power

2700 W

Input frequency

50/60 Hz

Emergency Power Off (EPO)

Y

Noise level

53 dB

Audible alarm(s)

Y

Battery

Battery technology

Sealed Lead Acid (VRLA)

Typical backup time at full load

5 min

Typical backup time at half load

17 min

Battery recharge time

3 h

Design

Cable length

2.44 m

Product colour

Black

Certification

CSA,FCC Part 15 Class A,UL 1778, RoHS 7b Exemption

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-15 - 45 °C

Weight & dimensions

Weight

63.6 kg

Other features

Interface

DB-9 RS-232, Smart-Slot

Output connections

9x NEMA 5-15R 2x NEMA 5-20R

Input connection type

NEMA L5-30P

Dimensions (WxDxH)

221 x 495 x 444 mm

Nominal output voltage

120 V

Nominal input voltage

120 V
